ALPALIUM Alkaline Button Cell AG10 / LR54 / 1130 / 1.5V / BP10

ALPALIUM Alkaline Button Cell AG10 / LR54 / 189 / V10GA / 1.5 V, 10pcs Blister

Mobile Energy for Everyday Use

Reliable energy supply for everyday use at home, in the office and on the go.

Versatile Applications

Suitable for numerous compatible battery-powered small devices, for example:

• Thermometers
• Calculators
• Digital measuring devices
• Laser pointers
• Wristwatches
• Small LED lights
• Toys
• Other small compatible electronic devices

Alkaline Technology

Proven alkaline technology with a nominal voltage of 1.5 volts for numerous standard applications.

Non-Rechargeable

Not a rechargeable battery. Alkaline primary button cell for single use.

Technical Data

• Brand: ALPALIUM
• Model designation: AG10-BP10
• Article No.: 14051010
• EAN Code: 4262420960227
• Battery type: Alkaline button cell / Primary battery
• Size: AG10 / LR54
• IEC designation: LR54
• Capacity: 78 mAh (measured at 10 kΩ down to a cut-off voltage of 0.9 V in accordance with the manufacturer's specifications)
• Electrochemical system: Alkaline zinc manganese dioxide system (Zn/MnO₂)
• Nominal voltage: 1.5 V
• Recommended operating temperature: −18 °C to +55 °C
• Recommended storage conditions: +15 °C to +25 °C at a relative humidity of 60 ±15 % in accordance with the manufacturer's specifications
• Dimensions: approx. 11.5 mm diameter × 3.1 mm height
• Weight per battery: approx. 1.2 g

Scope of Delivery

10 × ALPALIUM Alkaline Button Cells AG10 / LR54 / 1.5 V

Common Type Designations

AG10 / LR54 / 189 / G10 / V10GA / KA54 / GP189

Size-Compatible Silver Oxide Types

389 / 390 / SR54 / SR1130 / SR1130W / SR1130SW

Silver oxide batteries use a different cell chemistry and have different discharge characteristics. Before use, please check the battery designation and specifications required by the device manufacturer.

Safety and Usage Instructions

• Do not recharge
• Observe correct polarity (+/−)
• Do not short-circuit
• Do not dispose of in fire
• Keep out of reach of children
• Button cells can cause serious internal injuries and may be life-threatening if swallowed. If swallowing or insertion into any part of the body is suspected, seek immediate medical attention.

Information on Material Composition

Mercury, cadmium and lead are not intentionally added during the manufacturing process in accordance with applicable legal requirements.

Conformity & Safety

Complies with the applicable requirements of Regulation (EU) 2023/1542 concerning batteries and waste batteries.

Disposal Information

• Batteries must not be disposed of with household waste.
• Used batteries must be taken to an appropriate collection point in accordance with applicable legal requirements.
• Information on battery return and disposal: https://www.alpalium.com/batterieentsorgung
